Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
1 / 5
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves
Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves

Wholesale From China Factory 5-Layer Steel Medium Storage Racks Corrosion Protection Stacking Shelves

Send Inquiry

Product Description

Products Description
Adjustable Flexible Steel Shelving long span bolted racks heavy duty metal storage shelf racking warehouse racks
Our medium duty shelving is designed for small to medium sized goods in commercial and industrial warehouse storage settings -where goods are fast-moving and require easy access. It is basically an ideal storage system for hand stacking plus, the shelves are adjustable and can be customized as per the storage requirements.
Storage Rack Option 1
Storage Rack Option 2
Storage Rack Structural Detail 1
Storage Rack Structural Detail 2
Product Display 1
Product Display 2
Product Display 3
Description Upright Specification Beam Specification Thickness of the shelf Load capacity/layer
1500*500*2000 30*50*0.4mm 30*50*0.4mm 0.25mm 100kgs
2000*500*2000 30*50*0.4mm 30*50*0.4mm 0.25mm 100kgs
1500*600*2000 40*80*0.7mm 40*60*0.7mm 0.3mm 200kgs
2000*600*2000 40*80*0.7mm 40*60*0.7mm 0.3mm 200kgs
1500*600*2000 40*80*0.8mm 40*60*0.7mm 0.35mm 300kgs
2000*600*2000 40*80*0.8mm 40*60*0.7mm 0.35mm 300kgs
1500*600*2000 40*80*1.0mm 40*60*1.0mm 0.5mm 400kgs
2000*600*2000 40*80*1.0mm 40*60*1.0mm 0.5mm 400kgs
2000*600*2000 40*80*1.1mm 50*80.1.5mm 0.6mm 500kgs
Detailed Blueprint 1
Detailed Blueprint 2
Details Images
Component Exploded View
Joint Detail
Details 1
Upright: Upright is combined with horizontal bracing, diagonal bracing and bayonet. This structure is convenient to install and has stronger supporting power.

Beam: Special cold-rolled P-shaped closed beam is used for cross beam, which has the characteristics of simplicity, reliability, light weight, strong bearing capacity and low cost.
Details 2
Connector: Special design safety pin is equipped when the column clamp is connected with the column to ensure that the beam will not fall off under the impact of external force.

Shelf: Laminates adopt strip laminates made in the world, which have the characteristics of strong bearing capacity, wear resistance, simple replacement and low maintenance cost.
Shelving Component Diagram
Packing & Shipping
Flat Pack Packaging
Packing
1. KD structure, polyfoam between every part, packed in order and reasonable, not easy to shake.
2. Outside with five layers strong carton, tape sealing and packing belt to reinforce.
3. Can print LOGO or shipping mark as the customer wants.
Shipping Container Loading
Shipping
By Sea, By Air, By international Express.
Delivery Date within 10 days or according to your order quantity.
Exhibition
Trade Show Exhibition Booth
Our Company
Factory Warehouse Storage Solutions

We are one of the leading racking suppliers in China. We have shelving systems for any environment and racking systems for warehouses for all types of loads. We dedicate ourselves to provide quality racking systems at competitive prices.

Our main products are as follows:

  • Light Duty Racking Systems such as Boltless Rack
  • Medium Duty Racking Systems such as Valuespan Shelving Rack
  • Heavy Duty Racking Systems such as Selective Pallet Rack, Heavy Duty Shelving Rack
  • Warehouse Duty Racking Systems such as Heavy Duty Shelving cw Top Flooring, Multi-Tier Shelving System
  • Gondola Shelving System such as Wall Gondola, Cashier Counter
Factory Production Line
Certifications
Quality Standard Certifications
More Products
Recommended Products
Recommended Rack Type A
Recommended Rack Type B
Recommended Rack Type C
Recommended Rack Type D
Additional Product Solution 1
Additional Product Solution 2
Additional Product Solution 3
Warehouse Installation Showcase
FAQ
Are you a manufacturer or a trading company?
Yes, we are a professional manufacturer for steel furniture.
What is raw material & your products range?
The material is standard cold-rolled steel plate with Electrostatic Powder Coating Surface to avoid rusty. Our products range includes all kinds of steel office furniture, such as steel cabinets, mobile shelving, locker wardrobes, bunk beds, etc.
Can you customize and supply samples?
Yes, we offer custom-made service to our clients. You need to provide us some technical data such as dimension and drawing.
What is your production procedure?
Raw material - QC - cutting - pressing - bending - welding - QC - Phosphating - powder painting - QC - packing.
What's your packing?
Polyfoam + 5-layer corrugated carton. For LCL and sample, we will consider using a plywood case to reinforce and avoid damage during transportation.
Is assembly easy?
There is an assembling instruction in each carton. If you need, you will also receive our assembling video.
