| Model | Width * Depth * Height (mm) | Layers | Load Capacity | Specification Details |
|---|---|---|---|---|
| Light duty storage racks | 1200 * 400 * 2000 | 4 Layers | 100kg/Layers |
Frame: 30 * 50 * 0.6mm Beam: 30 * 50 * 0.4mm Steel panel: 0.3mm |
| 1200 * 500 * 2000 | ||||
| 1500 * 400 * 2000 | ||||
| 1500 * 500 * 2000 | ||||
| 2000 * 400 * 2000 | ||||
| 2000 * 500 * 2000 | ||||
| Medium duty storage racks | 1500 * 500 * 2000 | 4 Layers | 200kg/Layers |
Frame: 40 * 80 * 0.7mm Beam: 40 * 60 * 0.6mm Steel panel: 0.3mm |
| 1500 * 600 * 2000 | ||||
| 2000 * 500 * 2000 | ||||
| 2000 * 600 * 2000 | ||||
| Heavy Duty Pallet Racking System | 2000 * 600 * 2000 | 4 Layers | 300kg/Layers |
Frame: 40 * 80 * 0.7mm Beam: 40 * 60 * 0.7m Steel panel: 0.35mm |
| 2000 * 6000 * 2000 | 4 Layers | 400kg/Layers |
Frame: 40 * 80 * 1.0mm Beam: 40 * 60 * 1.0m Steel panel: 0.5mm |
|
| 2000 * 600 * 2000 | 4 Layers | 500kg/Layers |
Frame: 40 * 80 * 1.2mm Beam: 50 * 80 * 1.2m Steel panel: 0.6mm |
|
| The all size can be customized as requirement!!! | ||||
Qingdao port.
Our raw material is standard cold-rolled steel plate with an Electrostatic Powder Coating Surface to prevent rust.
Product Range: Various storage racks suitable for warehouses, logistics companies, and other environments that require efficient storage solutions.
Our standard factory colors include blue, white, orange, matte black, and matte gray.
Yes, we accept customization. The minimum order quantity for custom-sized shelves is 20 sets.
Absolutely. We employ a total of 9 production steps to ensure maximum rust prevention. The products are fully powder-coated, which is currently the most effective anti-rust treatment process.
Our standard delivery time is 10 days for full container loads (FCL) and 7 days for less than container loads (LCL).
