Can be customized according to your drawings and requirements
Detailed Specifications
Details 1
Upright:
Combined with horizontal bracing, diagonal bracing and bayonet. This structure is convenient to install and provides stronger supporting power.
Beam:
Special cold-rolled P-shaped closed beam is used for cross beam, which has the characteristics of simplicity, reliability, light weight, strong bearing capacity and low cost.
Details 2
Connector:
Special design safety pin is equipped when the column clamp is connected with the column to ensure that the beam will not fall off under the impact of external force.
Shelf:
Laminates adopt strip laminates made in the world, which have the characteristics of strong bearing capacity, wear resistance, simple replacement and low maintenance cost.
Key Features
✓Affordable and modular manual storage system for small goods.
✓Quick and easy to assemble, extend and adjust—virtually no tools required.
✓Available in standard frame widths of 1200mm, 1500mm and 2000mm, and depths varying from 400 to 600 mm.
✓Wide range of accessories for various storage methods.
✓Safe for employees and your products.
✓Available in blue, orange and other colors.
✓Load capacity available from 200 to 500 Kg per layer.
✓Standard layout configuration: 4 layers.
✓Low maintenance cost.
Product Specifications
Description
Upright Specification
Beam Specification
Thickness of the Shelf
Load Capacity / Layer
1500*500*2000
30*50*0.4mm
30*50*0.4mm
0.25mm
100kgs
2000*500*2000
30*50*0.4mm
30*50*0.4mm
0.25mm
100kgs
1500*600*2000
40*80*0.7mm
40*60*0.7mm
0.3mm
200kgs
2000*600*2000
40*80*0.7mm
40*60*0.7mm
0.3mm
200kgs
1500*600*2000
40*80*0.8mm
40*60*0.7mm
0.35mm
300kgs
2000*600*2000
40*80*0.8mm
40*60*0.7mm
0.35mm
300kgs
1500*600*2000
40*80*1.0mm
40*60*1.0mm
0.5mm
400kgs
2000*600*2000
40*80*1.0mm
40*60*1.0mm
0.5mm
400kgs
2000*600*2000
40*80*1.1mm
50*80*1.5mm
0.6mm
500kgs
More racking sizes and specifications are available.
Packaging & Shipping
01
KD Structure
Knock-down structure, with polyfoam between every part, packed in an orderly and reasonable layout to prevent shaking during transit.
02
Strong Outer Carton
Packaged in 5-layer strong export cartons, sealed with tape and reinforced with packing belts.
03
Customized Shipping Marks
Logo and shipping marks can be printed onto the cartons based on customer requirements.
04
Assembly Manual
Every product delivery package includes clear and detailed installation instructions.
Shipping Modes: By Sea, By Air, or via International Express. Delivery Time: Standard dispatch within 10 days, or adjusted according to final order quantities.
Frequently Asked Questions (FAQ)
Q1: Can these storage racks be customized to my specific layout requirements?
A1: Yes. We can design and customize the size, layers, and configuration of the shelving system according to your technical drawings and operational requirements.
Q2: What is the load capacity of this manual storage system?
A2: The loading capacity ranges from 200 Kg to 500 Kg per layer, depending on the column thickness, beam sizes, and overall shelf configurations selected.
Q3: How difficult is it to assemble this racking system?
A3: The system features a modular design that is quick and simple to install. It can be easily extended and adjusted, requiring virtually no specialized tools. Each package includes step-by-step instructions.
Q4: What material is used for the beams and shelves?
A4: The cross beams are made of cold-rolled P-shaped closed steel profiles which are lightweight and highly durable. The shelves feature wear-resistant, high-capacity steel strip laminates designed for easy replacement.
Q5: How are the racking components protected during shipping?
A5: We pack the racking systems in a knock-down (KD) structure. Every part is separated by protective polyfoam sheets, packed inside a heavy-duty 5-layer carton, and wrapped with shipping straps to prevent movement and damage.
Q6: What are the standard dimensions available for this system?
A6: Standard frame widths include 1200mm, 1500mm, and 2000mm, with frame depths ranging between 400mm and 600mm. The standard configuration comes with 4 adjustable layers.
